LED反光片，镭速光电最新推出，大陆独家供货

技术参数
额定电压：12V；

工作电压：12-15V；

LED颗数：24PCS，SMD3528；

圆形尺寸：直径50MM*高6MM；

方形尺寸：长89MM*宽35MM*高9.5MM；

材质：反射片（面）是PMMA材质； 反射器底座是ABS材质；

产品特性
原有反射器改装LED灯具，大小尺寸不变；

采用LED技术、信号极强；光反射距离可达300-500米；
背部螺钉固定，安装简易快捷；

极低的工作电流；
三线变光功能,一灯多用;黑线共阴,蓝线弱光,红线强光。

结构紧凑，重量轻，防震；

增加整车灯具功能和反射器功能；

镜片颜色分透明、琥珀色、红色；

LED颜色可以做成白光、红光、黄光、蓝光、绿光、紫光、粉红光、桃红光；

广泛运用在自行车、摩托车、汽车、卡车、船等交通工具，也可用做照明装饰

Specification:
Nominal voltage：12V；

Working Voltage：12-15V；

LED Quantity：24PCS，SMD3528；

Round Size：Diameter 50MM*Height 6MM；

Rectangle Size：Length 89MM*Width 35MM*Height 9.5MM；

Material：Reflector is PMMA, Reflector base is ABS；



Product Characteristics:

Modified from the original reflector, the size is same

Using LED technology; signal is extremely strong; Light reflecting distances can reach 300-500 meters

Back screws are fixed, installation is simple and quick;

Very low work current;
Three line and change light function, one light multi-purpose; the black line common cathode, the blue line is weak light, and the red line is strong light;

The structure is compact, light weight, shockproof;

Increase the function of vehicle lamps and reflector;

Lens color divides transparent, amber, and red;



The LED color can be made into white, red, yellow, green, blue, purple, pink Widely used in bicycle, motorcycle, automobile, truck, boat and so on, also can be used in lighting decoration
